Robust Heavy-Duty Flatbed Trailer for Demanding Transport

The ZW Group 2 Axle 40Ft Steel Flatbed Trailer redefines reliability in container and heavy cargo transport. Engineered with precision for Middle Eastern logistics, this heavy duty flatbed trailer combines superior load capacity (40,000kg) with unmatched structural integrity, making it a top choice for Oman's transport sector.

Engineering Excellence

• High-Strength Construction: Main beam fabricated from carbon steel Q345 (14mm upper plate + 16mm down plate) ensures maximum durability

• Enhanced Load Distribution: 500mm beam height with 8mm middle plate prevents deformation under heavy loads

• Premium Axle System: Dual 13TON axles with mechanical suspension for smooth operation on long hauls

Operational Advantages

This 2axles flatbed truck trailer delivers exceptional functionality:

• Container Versatility: 12 twist locks securely accommodate both 20ft and 40ft ISO containers

• Safety Features: 1500mm movable headboard + 14 removable side pipes prevent cargo shift

• Maneuverability: Optimized 12.5m length with 2.5m width balances cargo space and road compliance

Customization Options

ZW Vehicle Group offers customized semi-trailer services:

• Dimensions and Payload Capacity: Tailor the trailer's length, width, and height to match specific cargo requirements. You can also adjust the number of axles to achieve a higher payload capacity.

• Materials: Choose between different types of steel (e.g., high-tensile steel) or aluminum to optimize for durability, weight, and cost.

• Suspension System: Select from various suspension types, including air suspension, mechanical spring suspension, or bogie suspension, depending on the terrain and cargo type.

• Tire and Axle Configuration: Customize the number of axles (2-axle, 3-axle, etc.) and choose specific tire brands and sizes for optimal performance and load distribution.

• Accessories and Special Features: Add a wide range of accessories such as side fences, twist locks for container transport, spare tire carriers, toolboxes, and custom lighting configurations.

Specification

• -Overall Dimension :12500*2500*1550 (Lx W x H)(mm)

• -Loading Weight(KG): 40,000

• -Main Beam: the height of the beam is 500mm,upperplate is 14mm,down plate is 16mm, middle plate is8mm. With carbon steel Q345 high strength steel

• -Axle Brand: 13TON Axle, China brand

• -Axle Number: 2 axles

• -Suspension system:mechanical suspension-Platform plate: 3mm thickness Diamond plate

• -Tire Type and quantity: 315/80R22.5 tires,8 units.with triangle brand
